10.1 inch capacitive touchscreen for gaming consoles

Category:

1. Model number of quality 10.1 inch touch screen: 157ACSR101GG 2. Structure: Glass Lens+ITO Glass+FPC 3. Touch type: Single-touch or Multi touch 4. Application: Smart control, Industrial, Intelligent robots, Handheld device, etc 5. Interface type: IIC control 6. Color: Black

Description

10.1 inch capacitive touchscreen with IPS TFT module for gaming machine

Product name	10.1 inch capacitive touch screen
Brand Name	WIWOTOUCH
Material	Sodalime
Touch type	PCAP 10 points touch (Can be customized)
Application	Industrial, Handheld device, Smart control, etc
Interface type	IIC/USB
Structure	Glass Lens+ITO Glass+FPC
Cover Glass Dimension	237.86±0.2*147.86±0.2 mm
Cover Lens VA	216.98±0.15*135.76±0.15 mm
Cover Glass Thickness	0.7±0.05 mm
ITO Glass Thickness	0.55±0.05 mm
Total Thickness	1.7±0.1 mm
LCD resolution	TBD(As you need)
FPC	6 PIN
IC Model	FT5526EEZ/CH554G
Transmittance	≥85%
Surface Hardness	6H
Operating Environment	-20℃~+70℃,≤90%RH
Storage Environment	-30℃~+80℃,≤90%RH
Operating Voltage	2.8 V-3.3 V
Interface Voltage	2.8 V-3.3 V
Surface treatment	AR(Anti-reflective); AF(Anti-fingerprint); AG(Anti-glare); waterproof
General Tolerance	±0.2mm
Available operating systems	Android/Linux/Windows
Certificates	RoHS/Reach/ISO9001
Sample delivery	15 working days
Mass production delivery	2-4 weeks, according to customer requirements, the delivery time is slightly changed
Guarantee period	12 months
Packing	Plastic tray or antistatic bag or foam box or vacuum bag + carton

The use of touchscreens in gaming consoles can bring many benefits:

Intuitive operation: touch screens provide intuitive operation, allowing players to touch the screen with their fingers to operate the game without the need for an additional controller. This makes the game more accessible and reduces the learning curve, making it especially friendly for new players.

Multi-touch: The touch screen supports multi-touch technology, which recognises and responds to the actions of multiple fingers. This allows players to perform more complex gestures and operations, such as tapping, swiping, and zooming at the same time, adding to the interactivity and fun of the game.

Flexible gaming experience: The touchscreen brings greater flexibility to gaming consoles. It can accommodate a variety of game types, including platform games, puzzle games, shooting games, etc. Different types of games can be played with different touch gestures and operations to provide a unique gaming experience.

Innovative game play: Touch screen offers innovative possibilities for game developers. It can stimulate the creativity of game designers to develop unique and creative game play. For example, controlling character movement through finger swipes, releasing skills through buttons on the touch screen, etc.

Portability: Touch screen game consoles usually have a small size and lightweight design, making them easy to carry. Players can enjoy the game anytime and anywhere without the need to carry a separate large game controller or accessory.

The application of touch screen on the game machine needs to have high precision, sensitivity and response speed to ensure a good gaming experience. In addition, touchscreens need to be durable and scratch-resistant to accommodate long and frequent touch operations. Finally, for multiplayer games, the touch screen also needs to support simultaneous touch by multiple users to fulfil the demand for multiplayer online games.
