10.1-Inch IK10 Touch Panel: Durable, High-Performance Display for Diverse Applications

Category:

1.Model number: CSR101GG190-V2.0 2.Application: Smart control, Medical equipment, Industrial control, etc 3.Structure: Glass Lens + ITO glass sensor+FPC 4.Touch type: Multi touch(can be customized) 5. Certificates: Reach, RoHS, ISO9001

Description

10.1-Inch IK10 Touch Panel: Durable, High-Performance Display for Diverse Applications

Product name	10.1 Inch projected capacitive touch screen
Brand Name	WIWOTOUCH
Touch type	Multi touch(can be customized)
Application	Smart control, Medical, Industrial control, etc
Material	Asahi Dragon Trail
Interface type	IIC
Color	Black
Structure	Glass Lens+ITO sensor+FPC
Cover Glass Dimension	257.06±0.15*170.2±0.15 mm
Cover Lens VA	218.16±0.15*136.8±0.15 mm
Cover Lens Thickness	1.1±0.05 mm
Film sensor Thickness	0.7±0.05 mm
SCA	0.2 mm
Total Thickness	2±0.1 mm
LCD resolution	TBD(As you need)
IC Model	FT5526EEZ
FPC	6 PIN
Transmittance	≥85%
Surface Hardness	6 H
Operating Environment	-10℃~+60℃,≤45-90%RH
Storage Environment	-20℃~+70℃,≤45-90%RH
Operating Voltage	2.8 V-3.3 V
Interface Voltage	2.8 V-3.3 V
Surface treatment	As you need
General Tolerance	±0.2mm
Available operating systems	Android/Linux/Windows/Raspberry PI
Certificates	RoHS/Reach/ISO9001
Sample delivery	15 working days
Mass production delivery	2-4 weeks, according to customer requirements, the delivery time is slightly changed
Guarantee period	12 months
Packing	Plastic tray or antistatic bag or foam box or vacuum bag + carton

Features

Size:
- 10.1-inch display, suitable for medium to small devices, providing ample display space.
Durability:
- IK10 Rating: This rating indicates that the touch panel can withstand impacts of up to 20 joules, equivalent to a 5kg weight dropped from 400mm. Ideal for environments requiring high impact resistance.
- Scratch-Resistant: Made with robust glass material to prevent surface scratches.
Touch Technology:
- Supports capacitive or resistive touch technology. Capacitive touch screens are more responsive and support multi-touch, while resistive touch screens are suitable for operation with gloves or styluses.
Display Quality:
- High resolution: Provides clear and detailed images and text.
- High brightness and contrast: Readable in bright environments, suitable for outdoor use.
Environmental Adaptability:
- Water and Dust Resistance: Typically has a certain IP protection rating to prevent water and dust ingress, ensuring the device operates normally in harsh environments.
- Temperature Resistance: Can operate in extreme temperatures, suitable for various environmental conditions.

Applications

Industrial Automation:
- Used in factory automation control systems and equipment monitoring interfaces, requiring frequent operation and enduring harsh environments.
Public Facilities:
- Self-service kiosks, ticket machines, information kiosks, etc., capable of withstanding high-frequency and high-intensity use, preventing vandalism.
Retail and Service Industry:
- POS systems, information display screens, etc., providing a stable and responsive user experience.
Outdoor Equipment:
- Outdoor advertising displays, information boards, etc., suitable for various weather conditions, ensuring long-term stable operation.
Medical Devices:
- Medical equipment interfaces, capable of frequent cleaning and disinfection, ensuring responsiveness and accuracy.

This 10.1-inch IK10 touch panel, with its high durability and excellent display performance, is ideal for a wide range of applications that require a robust and reliable touch interface.
