10.1 Inch Capacitive Touch Panel For Industrial Control Device
1.Model number: CHL101GG0395 2.Application: Automotive, Medical device, Kiosk, etc 3.Structure: Glass Lens + ITO glass sensor+FPC 4.Touch type: Multi touch(can be customized) 5. Certificates: Reach, RoHS, ISO9001
Description
Product advantages：
1.Precise touch experience
• 10.1-inch highly sensitive capacitive screen, supporting 10-point touch + glove/wet hand operation mode
• Surface hardness of 6H tempered glass, anti-scuffing life > 5 million times
• Industrial-level anti-mis-touch algorithm
2. Industrial Environment Adaptability
• Wide operating temperature range: -10°C to +60°C
• IP65/IP67 protection grade, dust-proof, water-resistant, and oil-resistant
• Electromagnetic Interference (EMC) certification, suitable for complex electrical environments in factories
3. Compatibility and Scalability
• Diverse interfaces: USB/RS232/HDMI + customized industrial interfaces (such as GPIO)
• Pre-installed with Linux/Android systems, supporting Windows
4. Enhanced Durability Design
• Optional explosion-proof glass + nano-coating (for chemical/industrial site applications)
Product Parameter:
| Product name | 10.1 Inch Capacitive touch panel |
| Brand Name | WIWOTOUCH |
| Touch type | PCAP 10 points touch |
| Application | Industrial control, Medical device, POS system etc |
| Interface type | IIC/USB |
| Structure | Glass Lens+ITO Glass+FPC |
| Cover Glass Dimension | 228.86±0.2*148.5±0.2 mm |
| Cover Lens VA | 218.16±0.2*136.8±0.2mm |
| Cover Lens Thickness | 0.25 mm |
| ITO Glass Thickness | 1.1 mm |
| Total Thickness | 2.025±0.15 mm |
| LCD resolution | TBD(As you need) |
| IC Model | GT928 |
| FPC | 6 PIN |
| Transmittance | ≥85% |
| Surface Hardness | 3H |
| Operating Environment | -10℃~+60℃,≤90% RH |
| Storage Environment | -20℃~+70℃,≤90% RH |
| Operating Voltage | 2.8 V-3.3 V |
| Interface Voltage | 2.8 V-3.3 V |
| Surface treatment | AR(Anti-reflective); AF(Anti-fingerprint); AG(Anti-glare); waterproof |
| General Tolerance | ±0.2mm |
| Available operating systems | Android/Linux/Windows |
| Certificates | RoHS/Reach/ISO9001 |
| Sample delivery | 15 working days |
| Mass production delivery | 2-4 weeks, according to customer requirements, the delivery time is slightly changed |
| Guarantee period | 12 months |
| Packing | Plastic tray or antistatic bag or foam box or vacuum bag + carton |
Application
• Intelligent Factory Control Console
• Outdoor Construction Machinery
• Medical/Laboratory Equipment
