10.8 inch capacitive touch panel

Category:

Capacitive touch panel

Inquiry

PDF

NO. : 249ACFJ108GFF-V1.0 Type: Projected capacitive touch panel Structure: Glass+Glass IC: Atmel ATMXT295T2-C2UR030

Description

Product Feture

1.Strong durability, reducing loss costs
Adopting a Glass+Glass structure and featuring a surface hardness of ≥6H, it has excellent scratch resistance and wear resistance. During bulk usage, it can effectively reduce damage caused by daily wear and tear, lowering maintenance and replacement costs after purchase, and saving expenses for purchasers.

2.Has excellent environmental adaptability
It has excellent environmental adaptability, reducing adaptation troubles. The operating temperature range covers -20℃ to 70℃, and it can adapt to humidity from 45% to 90% RH. Whether in the cold outdoor environment of the north or the humid industrial workshop, it can operate stably. This feature significantly reduces various problems caused by environmental inadaptation after purchase, improving the adaptation efficiency of procurement.

3.The technical support is reliable

Adopting the mainstream IC solution of GT7387T + S819E ensures the stable performance of the product. We offer a 12-month warranty period and a prompt after-sales response. If non-human-induced quality issues occur within the warranty period, free returns and exchanges will be provided, allowing purchasers to buy with confidence.

Product Parameter

10.8 inch touch screen for outdoor interactive kiosks
Model NO.	CJL154GG0349-V2.0
Type	Projected capacitive touch panel
Structure	Glass+Glass
Product Dimensions	355.25±0.05234.25±0.051.3±0.05MM
Dimensions of Sensor Glass	354.25±0.2224.68±0.20.7±0.05MM
Area View	333.58±0.15*209.31±0.15MM
Thickness of Sensor Glass	0.7MM
Thickness of Cover Glass	0.475MM
Total Thickness	1.18±0.2MM
Surface hardness	≥6H
Transparency	≥83%
Operating temperature	–20℃~70℃ 45-90% RH
Storage temperature	–30℃~80℃ 45-90% RH
Surface treatment	AG+AR+AF
IC	GT7387T+S819E
Interface	I2C/USB
Touch-points	5-10 points
Precision	±1.0MM
Linearity	±1.0MM
Guarantee period	12 months
Packing	Plastic tray or antistatic bag or foam box or vacuum bag + carton

Product Application

1.Industrial Automation: Widely used in production line control panels, it features oil resistance and anti-interference properties, ensuring the stable operation of the production line.
2.Medical Equipment: As the touch screen of medical devices such as ultrasonic detectors, the high light transmittance ensures clear display of detection data, and the surface is easy to clean, meeting the requirements of the medical environment.
3.Smart Terminals: Applied in self-service vending machines, inquiry machines, etc., the wide temperature adaptation ability enables them to work normally in different seasons and environments.
