21.5 Inch Capacitive Touch Panel For Control Panel

Category:

1.Model number: CSR215GG211-V1.0 2.Application: Automotive, Medical equipment, Industrial control, etc 3.Structure: Glass Lens + ITO glass sensor+FPC 4.Touch type: Multi touch(can be customized) 5. Certificates: Reach, RoHS, ISO9001

Description

1. Product Overview

The 21.5-inch projection capacitive touchscreen of WIWOTOUCH is a high-quality product designed to meet the diverse needs of B2B customers. With its sturdy and durable structure and advanced functions, it is an excellent choice for various applications.

2. Key Features

Multi-touch function: Supports multi-touch and can be customized according to your specific needs. This makes the interaction more smooth and intuitive, enhancing the user experience in applications such as intelligent control systems.
Durable material: Made of sodium calcium glass, this touchscreen has high durability and can be used for a long time even in harsh environments.
Multi-function interface: Equipped with IIC interface, it is convenient for connection and compatible with various devices, allowing for easy integration into existing systems.
High light transmittance: Light transmittance ≥ 86%, providing clear and vivid visual display, suitable for applications with extremely high requirements for visual clarity, such as medical imaging and industrial control monitoring.
Surface hardness: 6H surface hardness can protect the screen from scratches and wear and tear, maintaining performance and appearance over a long period.

3.Technical Specifications

Product name	21.5 Inch projected capacitive touch screen
Brand Name	WIWOTOUCH
Touch type	Multi touch(can be customized)
Application	Smart control, Medical, Industrial control, etc
Material	Sodalime
Interface type	IIC
Color	Black
Structure	Glass Lens+ITO sensor+FPC
Cover Glass Dimension	533.4±0.3*324.86±0.3 mm
Cover Lens VA	476.64±0.3*268.11±0.3 mm
Cover Lens Thickness	3±0.1 mm
Film sensor Thickness	0.7±0.05 mm
SCA	0.2 mm
Total Thickness	3.9±0.3 mm
LCD resolution	TBD(As you need)
IC Model	ILI2302M
FPC	6 PIN
Transmittance	≥86%
Surface Hardness	6 H
Operating Environment	-20℃~+70℃,≤45-90%RH
Storage Environment	-30℃~+80℃,≤45-90%RH
Operating Voltage	3.3 V/5 V
Interface Voltage	3.3 V/5 V
Surface treatment	As you need
General Tolerance	±0.2mm
Available operating systems	Android/Linux/Windows/Raspberry PI
Certificates	RoHS/Reach/ISO9001
Sample delivery	15 working days
Mass production delivery	2-4 weeks, according to customer requirements, the delivery time is slightly changed
Guarantee period	12 months
Packing	Plastic tray or antistatic bag or foam box or vacuum bag + carton

4.Customized Service

Support custom size, bezel design and touch screen surface treatment to meet different customer needs.

Optional surface treatments such as anti-fingerprint, anti-glare, anti-reflection, and waterproof can significantly improve the readability, clarity, touch experience, and service life of capacitive touch screens.
Optional special coatings, such as anti-fingerprint and anti-bacterial finishes, enhance the user experience and product hygiene.
Frame design can be customized according to customer requirements, easy to integrate into a variety of equipment to meet different product appearance and functional needs, optional thickness and frame color enhance product flexibility and adaptability.

5. Certificates

Holds RoHS/Reach/ISO9001 certificates, demonstrating compliance with international standards for environmental protection and quality management. This gives you peace of mind in terms of product safety and quality.
